Russ Nickel Alloys is a premier manufacturer and supplier based in Manila, Philippines, specializing in high-quality zirconium sheets and plates. With a commitment to excellence, we provide a comprehensive range of products tailored to meet diverse industrial needs, including petrochemical, oil and gas, and chemical processing applications. We are renowned for our exceptional service, cutting-edge technology, and stringent quality control, ensuring that our zirconium sheets and plates offer superior corrosion resistance, durability, and mechanical properties. Our expertise and dedication make us a trusted partner in the industry.
Russ Nickel Alloys stands out as a top-notch manufacturer and supplier located in Manila, Philippines, specializing in high-quality Zirconium Sheets and Plates that are crafted for demanding industrial applications where performance and corrosion resistance are key. These products are celebrated for their remarkable strength, flexibility, and ability to withstand chemical attacks, making them perfect for environments that are both highly corrosive and high-temperature. At Russ Nickel Alloys, every Zirconium Sheet and Plate is made to meet international quality standards, ensuring they offer excellent dimensional accuracy, durability, and reliability. They find their place in various industries, including chemical processing, nuclear, aerospace, and medical, consistently delivering reliable performance even in the toughest conditions.
| Standard Specification : | ASTM B551 / ASME SB551 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Zirconium and Zirconium Alloys Chemical Composition | |||||||||
| Products | Chemical Composition (wt%≤) | ||||||||
| Sn | Fe | Ni | Cr | Fe+Cr | Fe+Ni+Cr | Nb | Al | B | |
| R60001 Nuclear Grade Pure Zirconium (Zr-0) | 0.005 | 0.15 | 0.0070 | 0.02 | – | – | – | 0.0075 | 0.0005 |
| R60802 (Zr-2) | 1.20-1.70 | 0.07-0.20 | 0.03-0.08 | 0.05-0.15 | – | 0.18-0.38 | – | 0.0075 | 0.0005 |
| R60804 (Zr-4) | 1.20-1.70 | 0.18-0.24 | 0.0070 | 0.07-0.13 | 0.28-0.37 | – | – | 0.0075 | 0.0005 |
| R60901 (Zr-2.5Nb) | 0.0050 | 0.150 | 0.0070 | 0.02 | – | – | 2.4-2.8 | 0.0075 | 0.0005 |
| R60904 (Zr-2.5Nb) | 0.010 | 0.065 | 0.0035 | 0.01 | – | – | 2.5-2.8 | 0.0075 | 0.0005 |
| Products | Chemical Composition(wt%≤) | ||||||||
| Cd | Co | Cu | Hf | Mg | Mn | Mo | Si | Ti | |
| R60001 Nuclear Grade Pure Zirconium (Zr-0) | 0.0005 | 0.0020 | 0.0050 | 0.010 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| R60802 (Zr-2) | 0.0005 | 0.0020 | 0.0050 | 0.010 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| R60804 (Zr-4) | 0.0005 | 0.0020 | 0.0050 | 0.010 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| R60901 (Zr-2.5Nb) | 0.0005 | 0.0020 | 0.0050 | 0.010 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| R60904 (Zr-2.5Nb) | 0.0005 | 0.0020 | 0.0050 | 0.005 | 0.0020 | 0.0050 | 0.0050 | 0.0120 | 0.0050 |
| Products | Chemical Composition (wt%≤) | ||||||||
| U | V | W | C | N | H | O | |||
| R60001 Nuclear Grade Pure Zirconium (Zr-0) | 0.0035 | 0.005 | 0.010 | 0.027 | 0.0065 | 0.0025 | 0.09-0.16 | ||
| R60802 (Zr-2) | 0.0035 | 0.005 | 0.010 | 0.027 | 0.0065 | 0.0025 | 0.09-0.16 | ||
| R60804 (Zr-4) | 0.0035 | 0.005 | 0.010 | 0.027 | 0.0065 | 0.0025 | 0.09-0.16 | ||
| R60901 (Zr-2.5Nb) | 0.0035 | – | 0.010 | 0.027 | 0.0080 | 0.0025 | 0.09-0.15 | ||
| R60904 (Zr-2.5Nb) | 0.0035 | 0.005 | 0.010 | 0.027 | 0.0065 | 0.0025 | 0.01-0.14 | ||
| Zirconium and Zirconium Alloys Sheet & Plate Mechanical Properties | |||||
| Grades | |||||
| Products | R60700 | R60702 | R60704 | R60705 | R60706 |
| Tensile strength, min, ksi (MPa) | – | 55 (380) | 60 (415) | 80 (550) | 74 (510) |
| Yield strength, min, ksi (MPa) | – | 30 (205) | 35 (240) | 55 (380) | 50 (345) |
| Tensile strength, max, ksi (MPa) | 55 (380) | – | – | – | – |
| Yield strength, max, ksi (MPa) Sheet, Plate and Strip | 44 (305) | – | – | – | – |
| Elongation in 2 in. or 50 mm, min, % | 20 | 16 | 14 | 16 | 14 |
| Bend test radius | 5T | 5T | 5T | 3T | 2.5T |
The Zirconium Sheets and Plates are produced from high-purity zirconium, typically with low hafnium content to boost their corrosion resistance in acidic and chloride-heavy settings. They boast impressive mechanical properties, such as high tensile strength, good ductility, and exceptional resistance to oxidation and corrosion. With a high melting point of around 1855°C, low neutron absorption, and excellent thermal stability, these sheets and plates are perfect for applications where both structural integrity and chemical resistance are essential.
Contact us to get a quick quote for your requirement.
In the chemical and petrochemical sectors, Zirconium Sheets and Plates are commonly used to manufacture reactors, heat exchangers, piping systems, and vessels that come into contact with aggressive chemicals. In the nuclear field, they serve as cladding for fuel rods and other components that require low neutron absorption. Additionally, they are utilized in aerospace for high-temperature structural components and in the medical industry for surgical implants and devices, thanks to their biocompatibility. With their outstanding corrosion resistance, thermal stability, and mechanical strength, Zirconium Sheets and Plates are the go-to choice for high-performance and safety-critical applications.
