Russ Nickel Alloys is a trusted manufacturer and supplier of high quality nickel alloy products in Manila, Philippines, specializing in alloy C263 sheet and plate Exceptionally known for its heat and corrosion resistance, these alloys are used in airspace, power generation and industrial applications They produce they are used in many ways. With a strong commitment to quality, consistency and customer satisfaction, Russ Nickel Alloy offers reliable solutions tailored to the needs of various industries. Choose us for the best products, competitive prices and fast delivery throughout the Philippines.
Russ Nickel Alloys, located in Manila, Philippines, stands out as a dependable manufacturer and supplier of top-notch welding consumables. They specialize in AWS Class ERNiCrCoMo-1 MIG and TIG Filler Welding Wire and Rod. With a strong focus on quality, precision, and durability, this company serves a diverse array of industries that need exceptional welding solutions for high-temperature and corrosion-resistant applications. Russ Nickel Alloys takes pride in delivering expertly crafted filler materials that adhere to international standards, making them a go-to partner for welding professionals in fields like aerospace, power generation, chemical processing, and marine engineering throughout the Philippines and beyond.
| Standard Specification : | AMS 5872 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | Ni | Co | Cr | Mo | Ti | Fe | Mn | Al | Si | Cu | C | B | S |
| Alloy C263 | 49 | 19-21 | 19-21 | 5.60-6.10 | 1.90-2.40 | 0.70 | 0.60 | 0.60 | 0.40 | 0.20 | 0.040 – 0.080 | 0.0050 | 0.0070 |
| Material | Temp °C | Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation % | Hardness HRC |
|---|---|---|---|---|---|
| Alloy C263 Solution Treated (AMS 5872 / BS HR206) | RT | – | – | – | 22.5 max |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | RT | 580 (typical) | 973 (typical) | 39 – | |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | 780 | 403 (min) | 541 (min) | 9 | – |
The AWS Class ERNiCrCoMo-1 MIG and TIG Filler Welding Wire and Rod are primarily made of nickel (Ni), with notable amounts of chromium (Cr) at 20–23%, cobalt (Co) at 10–15%, and molybdenum (Mo) at 8–10%. This thoughtfully designed composition provides remarkable mechanical strength, with typical tensile strength hitting 760 MPa (110 ksi) and an elongation of about 30%. The alloy is specifically engineered for outstanding high-temperature stability, corrosion resistance, and weldability, making it perfect for challenging environments. Its performance characteristics ensure structural integrity even under extreme thermal conditions, offering a long service life in critical industrial applications.
Contact us to get a quick quote for your requirement.
These AWS Class ERNiCrCoMo-1 MIG and TIG Filler Welding Wire and Rod are widely utilized for welding nickel-based alloys like Alloy 617 and other high-temperature materials. They are crucial in industries that demand excellent resistance to oxidation, carburization, and corrosion, particularly at temperatures above 1000°C. Common uses include gas turbines, heat exchangers, furnace components, reformer tubes, and pressure vessels in power plants, petrochemical facilities, and aerospace settings. Their exceptional metallurgical properties and reliability under intense stress make them a preferred choice for both fabrication and repair.
