Russ Nickel Alloys, located in Manila, Philippines, has built a solid reputation as a reliable manufacturer and supplier of top-notch Inconel 718 stud bolts, specifically serving clients in Dubai, UAE. Known for their precision engineering and strict quality standards, the company consistently delivers products that align with international specifications and industry needs. With a strong emphasis on reliability and durability, Russ Nickel Alloys makes sure that every Inconel 718 stud bolt goes through thorough inspection and testing, guaranteeing clients exceptional performance even in the toughest environments. Their dedication to excellence, prompt delivery, and competitive pricing has made them a go-to partner for industrial fasteners and high-performance alloy solutions across various sectors.
Inconel 718 stud bolts are primarily made up of nickel (50–55%), chromium (17–21%), and iron (the balance), along with trace amounts of niobium, molybdenum, titanium, and aluminum. This superalloy boasts remarkable mechanical properties, such as high tensile strength (up to 1,275 MPa), excellent yield strength, and impressive fatigue resistance. It maintains its structural integrity under extreme temperatures, from cryogenic conditions all the way up to 700°C, and shows outstanding resistance to corrosion and oxidation. These characteristics make Inconel 718 stud bolts perfect for high-stress environments, thermal cycling, and exposure to harsh chemicals or saline conditions, ensuring they perform reliably over time.
| Specification | ASTM F468, B637 / ASME SF468, SB637 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 718 | 0.08 max | 0.35 max | 0.35 max | 0.015 max | 0.30 max | – | 50.00 – 55.00 | 17.00 – 21.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
At Russ Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 718 Stud Bolts in Manila, Philippines, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Philippines, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 718 stud bolts find extensive applications in the aerospace, marine, and petrochemical industries due to their ability to endure extreme conditions. They play a crucial role in fastening components in gas turbines, jet engines, and nuclear reactors, where resistance to high temperatures and stress is vital. In chemical processing plants and offshore oil rigs, these bolts provide secure assembly in corrosive and high-pressure environments. Additionally, they are used in power generation equipment, automotive engines, and heavy machinery, offering durability and safety.
