Russ Nickel Alloys, located in Manila, Philippines, stands out as a top manufacturer and supplier of high-quality Inconel 600 stud bolts, catering to industrial clients in Dubai, UAE. The company is well-known for its dedication to precision engineering and strict quality standards, providing fasteners that not only meet international specifications but also perform exceptionally well in extreme conditions. With state-of-the-art manufacturing facilities and a talented workforce, Russ Nickel Alloys guarantees that every product is reliable, durable, and resistant to corrosion. Serving a wide array of industries, the company has built a solid reputation for delivering Inconel 600 stud bolts that can handle the toughest applications.
Inconel 600 stud bolts are primarily made up of nickel (72%), chromium (14–17%), and iron (6–10%), along with trace amounts of manganese, silicon, and carbon. This unique alloy offers outstanding resistance to oxidation, corrosion, and high-temperature scaling. In terms of mechanical properties, these stud bolts boast a tensile strength of about 80–100 ksi and a yield strength ranging from 35–60 ksi, with an elongation of around 30%. Their impressive strength and stability at high temperatures, combined with excellent toughness and fatigue resistance, make them perfect for extreme industrial environments where standard fasteners might fail.
| Specifications | ASTM A166 / ASME A166 |
| Standard | DIN, ISO ,JIS ,GB, IS, BS, ASTM and all International Standards |
| Size | M3 – M100 | 3/6″ – 4″ | Custom Sizes |
| Length | 3 mm – 200 mm | Custom Sizes |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Head | Hex, Square, Round, Hex flange, Flat, T-head & Triangular etc. |
| Neck type | Hex, Square, Triangular, Oval & Knurled etc. |
| Surface Treatment | Passivation /plain |
| Others Factor | OEM, ODM, ±0.03MM tolerance |
| Manufacturing Process | Wire Drawing, Cold Heading, Insert tapping, Heat Treatment, Surface Plating, Inspection, Packing. |
| Packing | IN BULK: carton, pallet, Small Boxes or customer request |
| Surface Coating | Black Oxide, Cadmium, Galvanized, Teflon, Xylan, Zinc, Others Upon Request |
| Test Certificate | As per EN 10204 / 3.1 Manufacturer Test Certificate, PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
At Russ Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 600 Stud Bolts in Manila, Philippines, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Philippines, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
These Inconel 600 stud bolts are commonly found in chemical processing, petrochemical plants, and power generation sectors, thanks to their remarkable resistance to corrosive environments and high temperatures. They play a crucial role in securing flanges, pressure vessels, heat exchangers, and piping systems that endure stress and thermal cycling. Moreover, these bolts are also utilized in marine engineering, aerospace, and nuclear industries, where reliability and safety are paramount. Their ability to maintain mechanical integrity in harsh conditions ensures a long service life and minimal maintenance, making them the go-to choice for demanding industrial fastening needs.
