Russ Nickel Alloys, located in Manila, Philippines, has earned a solid reputation as a reliable manufacturer and supplier of Inconel 625 Stud Bolts in Dubai, UAE. Renowned for their exceptional quality and precision engineering, this company produces stud bolts that not only meet international standards but also excel in tough environments. Russ Nickel Alloys takes pride in ensuring that each product showcases remarkable resistance to oxidation, corrosion, and high temperatures. With cutting-edge manufacturing technology and rigorous quality control, their Inconel 625 Stud Bolts are perfect for demanding sectors like marine, chemical, and aerospace, where durability and reliability are absolutely crucial.
Inconel 625 Stud Bolts are primarily made from nickel, chromium, and molybdenum, with niobium added to boost strength and toughness. They boast impressive mechanical properties, including high tensile strength, excellent fatigue resistance, and outstanding creep rupture strength, even at elevated temperatures. These bolts also offer remarkable corrosion resistance in both oxidizing and reducing environments. The unique blend of elements ensures great weldability and resistance to stress corrosion cracking, making them ideal for high-performance applications that require durability and stability in extreme conditions.
| Specification | ASTM F468, B166 / ASME SF468, SB166 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
At Russ Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 625 Stud Bolts in Manila, Philippines, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Philippines, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 625 Stud Bolts are extensively utilized in industries that require high strength and corrosion resistance under severe conditions. You’ll often find them in offshore oil and gas platforms, chemical processing plants, heat exchangers, and marine engineering systems. They’re also used in aerospace structures, nuclear reactors, and power generation equipment, thanks to their stability under thermal and mechanical stress. Their ability to resist oxidation while maintaining mechanical integrity in aggressive environments makes them a top choice for critical fastening solutions in high-pressure and high-temperature applications.
