Home > Nickel Alloys > AWS Class ERNiCrMo-10 MIG and TIG Filler Welding Wire and Rod
Russ Nickel Alloys, based in Manila, Philippines, has built a solid reputation as a reliable manufacturer and supplier of top-notch welding consumables, including the AWS Class ERNiCrMo-10 MIG and TIG filler welding wire and rod. Known for their precision engineering and commitment to global standards, Russ Nickel Alloys delivers cutting-edge welding solutions for industries that require outstanding corrosion resistance and mechanical strength. Their ERNiCrMo-10 filler metals are crafted for exceptional weld performance, catering to critical sectors like chemical processing, power generation, marine, and aerospace.
AWS Class ERNiCrMo-10 is a nickel-based alloy primarily made up of nickel, chromium, molybdenum, and tungsten, with smaller amounts of iron and other trace elements. The typical makeup consists of around 62% nickel, 22% chromium, 13% molybdenum, and 3% tungsten. This unique blend offers remarkable resistance to both oxidizing and reducing chemicals, particularly in harsh environments filled with chlorides and acids. On the mechanical side, ERNiCrMo-10 boasts high tensile strength, excellent ductility, and impressive resistance to stress corrosion cracking and pitting, even at elevated temperatures.
| Classification | AWS A5.14, ERNiCrMo-10 |
| Form | MIG spools, TIG cut lengths, Reels and Coils |
| Type Of Welding | Inert Gas Welding |
| Standard TIG straight lengths are available | 36” (914 mm) or 39” (1000 mm) lengths. Other lengths available upon request. |
| AWS ERNiCrMo-10 MIG & TIG Filler Metal Application & uses |
|
| C | Mn | Fe | P | S | Si | Cu | Ni | Co | Cr | Mo | V | W | Other |
| 0.015 | 0.50 | 2.0-6.0 | 0.02 | 0.010 | 0.08 | 0.50 | Rem | 2.5 | 20.0-22.5 | 12.5-14.5 | 0.35 | 2.5-3.5 | 0.5 |
| Tensile (psi) | 100,000 |
|---|---|
| Mpa | 690 |
| Elongation (%) | 30 |
At Russ Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of AWS Class ERNiCrMo-10 MIG and TIG Filler Welding Wire and Rod in Manila, Philippines, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Philippines, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
AWS Class ERNiCrMo-10 MIG and TIG filler welding wire and rod are widely utilized in industries where components face extreme chemical and thermal challenges. Common uses include welding nickel-chromium-molybdenum alloys like Hastelloy C-22 and other corrosion-resistant materials. It’s perfect for fabricating reactors, heat exchangers, pressure vessels, and piping systems in chemical and petrochemical plants. Thanks to its outstanding weldability, toughness, and corrosion resistance, ERNiCrMo-10 is the go-to choice for critical structures operating in severe, high-temperature, and chloride-rich environments.
