Russ Nickel Alloys stands out as a reliable manufacturer and supplier of Rene 41 Sheets and Plates right in the heart of Manila, Philippines. They cater to a diverse array of high-performance industries, earning a solid reputation for their precision engineering and the use of cutting-edge materials. Their Rene 41 products are top-notch, meeting the rigorous standards of global aerospace and industrial sectors. With a strong focus on quality, reliability, and technical know-how, Russ Nickel Alloys offers heat-resistant and high-strength solutions designed for the toughest environments. Clients in aviation, defense, and energy sectors trust their Rene 41 Sheets and Plates for dependable performance, even under intense stress and high temperatures.
Rene 41 Sheets and Plates are crafted from a nickel-based superalloy that boasts significant amounts of chromium, cobalt, and molybdenum, along with trace elements that boost strength and oxidation resistance. Typically, this alloy is composed of about 57% nickel, 19% chromium, 11% cobalt, and 10% molybdenum. It showcases remarkable mechanical properties, even at temperatures soaring up to 1600°F (870°C), featuring high tensile strength, impressive creep resistance, and excellent thermal stability. These traits make Rene 41 the go-to material for components that face both mechanical loads and elevated temperatures over extended periods.
| Standard Specification : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
You’ll find Rene 41 Sheets and Plates widely utilized in the aerospace, defense, and power generation industries, thanks to their outstanding strength and thermal performance. They’re commonly used in the production of jet engine components, afterburner parts, turbine blades, and structural elements that endure extreme heat and pressure. In the energy sector, these materials play a crucial role in high-temperature reactors and heat exchangers. Their resistance to corrosion and oxidation also makes them ideal for chemical processing equipment and marine environments where durability is key.
Contact us to get a quick quote for your requirement.
Rene 41 sheets and plates are very useful in applications requiring exceptional resistance to heat and oxidation. Because they can withstand temperatures up to 980°C (1800°F), they are widely used in aerospace applications, such as gas turbine engines, afterburners, and exhaust components These materials are used in rocket engines, medical devices , industrial -and furnace. The high strength and corrosion resistance of René 41 makes it ideal for applications under severe thermal and mechanical stresses.
