Home > Rene 41 Foil
Russ Nickel Alloys is a leading manufacturer and supplier based in Manila, Philippines, specializing in high quality nickel alloys and related products Committed to excellence the company offers a wide range of known Rene 41 foil it as exceptional strength, corrosion resistance and high temperature performance include for , meanwhile Ensures delivery and customer service, and making them a reliable partner for any alloying needs in the region.
Russ Nickel Alloys stands out as a top-notch manufacturer and supplier of Rene 41 foil right in the heart of Manila, Philippines. Renowned for their exceptional quality and precision in manufacturing, they focus on creating Rene 41 foil that boasts tight thickness tolerances and a superior surface finish. Thanks to their cutting-edge production techniques, every piece of foil meets the strict standards set for aerospace and industrial applications. Catering to clients in Manila and beyond, Russ Nickel Alloys delivers reliable, high-performance Rene 41 foil that’s built to handle demanding tasks, offering excellent strength and heat resistance.
| Standard Specification : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
The Rene 41 foil produced by Russ Nickel Alloys in Manila is primarily made from a nickel-cobalt alloy, enhanced with chromium, molybdenum, titanium, and aluminum. This unique blend gives it remarkable mechanical properties, such as high tensile strength, creep resistance, and outstanding oxidation resistance at high temperatures. The foil’s fine grain structure, combined with its well-balanced alloying elements, ensures durability and stability, making it perfect for high-temperature settings where both strength and resistance to corrosion are essential.
Contact us to get a quick quote for your requirement.
| Grade | UNS | Workstoff | AMS | GE |
| Rene 41 | N07041 | 2.4973 | AMS 5545, AMS 5712, AMS 5713, AMS 5800 | GE B50TF109, GE B50TF76 |
Russ Nickel Alloys’ Rene 41 foil finds its way into various applications, including aerospace, gas turbine engines, and high-performance industrial sectors. Its impressive strength-to-weight ratio and resistance to thermal fatigue make it an ideal choice for turbine blades, combustion chambers, and other critical components that face extreme heat and stress. Moreover, Rene 41 foil is utilized in advanced manufacturing processes that demand precise material thickness and uniformity. Russ Nickel Alloys is committed to ensuring that their Rene 41 foil products meet stringent industry specifications, providing customers in Manila with dependable materials for innovative engineering solutions.
