Russ Nickel Alloys, located in Manila, Philippines, is a trusted manufacturer and supplier of top-notch nickel-copper alloy products. They specialize in Monel Ball Valves, which are well-known for their outstanding corrosion resistance and durability, especially in tough industrial and marine settings. With a commitment to quality and precision, Russ Nickel Alloys ensures that their valves comply with international standards, catering to industries that need reliable and sturdy flow control solutions. Their expertise means customers can count on Monel ball valves designed for long-lasting performance, safety, and dependability.
Monel Ball Valves are crafted from a nickel-copper alloy that consists of about 67% nickel and 30% copper, along with small amounts of iron and manganese to boost strength and toughness. This unique blend offers remarkable resistance to seawater corrosion, acids, alkalis, and high-temperature oxidation. Additionally, Monel valves maintain excellent mechanical strength and dimensional stability, even under extreme pressure and corrosive conditions.
| VALVE SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.34, ASTM A494/ASME SA494, ASME B 16.5, ASME B 16.10, BS EN 12266-1/API 598, BS1414/ API 600, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Ni | Mn | C | Si | Cu | S | Fe | Cr |
| Monel 400 | 63.00 min | 2.00 max | 0.30 max | 0.50 max | 28.0-34.0 | 0.24max | 2.50 max | – |
| Element | Melting Point | Yield Strength (0.2%Offset) | Elongation | Density | Tensile Strength |
| Monel 400 | 1350 °C (2460 °F) | Psi – 35,000 , MPa – 240 | 40 % | 8.8 g/cm3 | Psi – 80,000 , MPa – 550 |
At Russ Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Monel Ball Valve in Manila, Philippines, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Philippines, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
These Monel Ball Valves find extensive use in marine engineering, chemical processing, offshore oil and gas operations, and desalination plants. They are perfect for managing fluid flow in systems that encounter seawater, acidic solutions, and other corrosive environments. The combination of strength, corrosion resistance, and leak-tight sealing performance makes Monel ball valves a fantastic choice for critical industrial applications.
