Home > Invar 36 Sheet and Plates
Russ Nickel Alloys, located in Manila, Philippines, has built a solid reputation as a reliable manufacturer and supplier of top-notch metal products, including Invar 36 Sheets and Plates. Renowned for their precision, dimensional stability, and dependability, the company crafts sheets and plates that adhere to international standards for mechanical performance and thermal properties. The Invar 36 Sheets and Plates from Russ Nickel Alloys are designed with an incredibly low coefficient of thermal expansion, making them perfect for applications that demand minimal expansion with temperature fluctuations. These products deliver enduring performance, exceptional stability, and accuracy for aerospace, instrumentation, and industrial projects.
Invar 36 Sheets and Plates are crafted from a nickel-iron alloy that contains about 36% nickel. This unique blend results in an incredibly low coefficient of thermal expansion, outstanding dimensional stability, and solid mechanical strength. They maintain their structural integrity even under thermal cycling and resist warping or distortion in critical applications. The sheets and plates are also known for their good workability, toughness, and durability, making them ideal for precision engineering, aerospace, electronics, and other sectors where thermal stability and mechanical reliability are crucial.
| Standards : | ASTM F1684 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Shims Thickness : | Range from .01″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc |
| Grade | C | Mn | Si | S | Co | Fe | Mo | Al |
| Invar 36 | .008 max | .30 max | .15 max | .001 max | .35 max | 63.0 max | .02 max | .03 max |
| Element | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Invar 36 | KSI (MPa) 63 / (430) Max | KSI (MPa)-38 / (260) Max | 30 % |
| STANDARD | WERKSTOFF NR. | UNS |
| Invar 36 | 1.3912 | K93600 | K93603 |
At Russ Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Manila, Philippines, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Philippines, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Invar 36 Sheets and Plates find extensive use in industries that require minimal thermal expansion and high dimensional stability. They’re commonly utilized in aerospace components, precision instruments, optical devices, scientific equipment, and industrial molds. These products are particularly suited for parts that experience temperature fluctuations, where maintaining precise dimensions is vital. Invar 36 Sheets and Plates from Russ Nickel Alloys guarantee long-term reliability, precision, and performance. Their exceptional combination of thermal stability, mechanical strength, and durability makes them the go-to choice for demanding applications in aerospace, electronics, and beyond.
