At Russ Nickel Alloys, a premier manufacturer and distributor in Manila, Philippines, we specialize in high-quality Hastelloy forged fittings. Our products are designed to meet the most demanding industrial standards, offering exceptional resistance to corrosion and high temperatures. With a commitment to precision and excellence, we provide a comprehensive range of Hastelloy fittings that ensure durability and reliability in critical applications. Whether you’re in the oil and gas, chemical processing, or aerospace sectors, our forged fittings are engineered to perform under the toughest conditions. Trust Russ Nickel Alloys for unmatched quality and performance in Hastelloy products.
| Specifications | ASTM B366/ ASME SB366 |
|---|---|
| Size | Seamless Butt Weld Fittings : 1/2″ – 10″ Welded Butt Weld Fittings : 1/2″ – 48″ |
| Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10 |
| Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| Connection | Welding |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Manufacturing process | Push, Press, Forge, Cast, etc. |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Cross, Reducer, Pipe Cap, Stub End, Pipe Bend |
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| C276 | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
| C22 | 0.010 max | 0.50 max | 0.08 max | 0.02 max | 2.50 max | 50.015 min* | 20.00 – 22.50 | 2.00 – 6.00 | 12.50 – 14.50 | 0.02 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
| Hastelloy C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
Constructed from high-performance nickel-based Hastelloy alloys, these fittings primarily consist of nickel, molybdenum, iron, and trace amounts of chromium and other alloying elements. This unique blend provides excellent tensile and yield strength, superior toughness, and exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking, even in highly acidic, oxidizing, and chloride-rich conditions. The forging process further enhances their mechanical properties, ensuring they maintain dimensional stability, impact resistance, and long-term durability.
Contact us to get a quick quote for your requirement.
Hastelloy Forged Fittings are commonly utilized in chemical and petrochemical plants, oil and gas refineries, power generation facilities, and marine systems for connecting pipes, valves, and equipment in critical process lines. They excel in applications that deal with corrosive fluids, high-pressure systems, and high-temperature processes where mechanical integrity and chemical resistance are crucial. With their superior strength, corrosion resistance, and long-term reliability, Hastelloy Forged Fittings are the go-to choice for demanding, high-performance, and safety-critical industrial applications.
