Russ Nickel Alloys, a leading manufacturer and distributor based in Manila, Philippines, specializes in high-quality Hastelloy C276 forged fittings. Our Hastelloy C276 fittings are engineered to deliver superior resistance to corrosion and high-temperature performance, making them ideal for demanding industrial environments. With a commitment to excellence and precision, we provide reliable solutions tailored to meet the needs of diverse applications. Trust Russ Nickel Alloys for top-tier Hastelloy C276 products that ensure durability and efficiency in even the harshest conditions.
| ASTM B564 – ASME SB564 | Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings |
| ASME B16.9 | Factory-Made Wrought Buttwelding Fittings |
| ASME B16.11 | Socket Welding and Threaded Forged Fittings |
| MSS SP-43 | Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications |
| MSS SP-95 | Swage(d) Nipples and Bull Plugs |
| BS3799 | Specification for Steel pipe fittings, screwed and Socket-welding for the petroleum industry |
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| Hastelloy C276 | 0.010 max | 1.00 max | 0.08 max | 0.03 max | 2.50 max | 50.99 min* | 14.50 – 16.50 | 4.00 – 7.00 | 15.00 – 17.00 | 0.04 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C276 | 8.89 g/cm3 | 1370 °C (2500 °F) | Psi – 1,15,000 , MPa – 790 | Psi – 52,000 , MPa – 355 | 40 % |
Constructed from Hastelloy C276 alloy—a blend of nickel, molybdenum, and chromium with trace amounts of iron and tungsten—these fittings boast remarkable tensile and yield strength, excellent toughness, and outstanding resistance to pitting, crevice corrosion, and stress corrosion cracking. This is particularly true in both oxidizing and reducing environments, including strong acids like hydrochloric, sulfuric, and nitric acid. The forging process not only enhances their mechanical properties but also improves dimensional stability and fatigue resistance, making these fittings incredibly reliable for critical industrial systems.
Contact us to get a quick quote for your requirement.
Hastelloy C276 Forged Fittings are commonly found in chemical and petrochemical plants, oil refineries, desalination facilities, and marine systems, where they connect pipes, valves, and equipment that handle highly corrosive fluids and gases. They excel in high-pressure, high-temperature, and chemically aggressive settings, where corrosion resistance and mechanical integrity are crucial. With their superior strength, corrosion resistance, and long-lasting durability, Hastelloy C276 Forged Fittings are the go-to choice for demanding, high-performance, and safety-critical industrial applications.
