Home > Duplex Steel > Duplex Steel S32205 Sheet and Plates
At Russ Nickel Alloys, we pride ourselves on being a leading manufacturer and distributor of Duplex Steel S32205 sheets and plates in Manila, Philippines. Our Duplex Steel S32205 products are renowned for their exceptional strength, superior corrosion resistance, and durability, making them ideal for demanding industrial applications. With a commitment to quality and precision, we supply high-performance materials tailored to meet the specific needs of our clients. Whether you’re in construction, petrochemical, or marine industries, Russ Nickel Alloys ensures reliable, top-tier solutions for all your steel requirements. Trust us for excellence in every sheet and plate we deliver.
Specifications : ASTM A240 / ASME SA240
Dimensions : ASTM, ASME, and API
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Thickness : 4mm-100mm
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Surface Finish : 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| Duplex 2205 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 – 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32205 | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
These sheets and plates are made from a nitrogen-enhanced duplex stainless steel alloy, featuring a balanced mix of austenite and ferrite phases. The alloy’s composition includes chromium, nickel, molybdenum, and nitrogen, which together provide outstanding tensile and yield strength, excellent resistance to pitting, crevice corrosion, and stress corrosion cracking, along with improved weldability. Even in high-temperature and chloride-rich environments, this alloy maintains good toughness and structural stability.
Contact us to get a quick quote for your requirement.
Duplex Steel S32205 Sheets and Plates find extensive use in chemical and petrochemical plants, oil refineries, offshore platforms, power generation systems, and marine settings. They are perfect for fabricating pressure vessels, heat exchangers, storage tanks, and structural components that demand both corrosion resistance and high mechanical strength. Thanks to their exceptional durability, corrosion resistance, and long-term performance, Duplex Steel S32205 Sheets and Plates are the go-to choice for high-performance, safety-critical, and demanding industrial applications.
