Russ Nickel Alloys, located in Manila, Philippines, has built a solid reputation as a reliable manufacturer and supplier of high-quality stainless steel and nickel alloy products. Among their offerings are Duplex Steel 2205 Sheet and Plates, which stand out for their remarkable corrosion resistance, impressive tensile strength, and exceptional durability. With a strong focus on quality and precision, Russ Nickel Alloys guarantees that their sheets and plates adhere to international standards, delivering dependable material solutions for even the most demanding industrial applications.
Specifications : ASTM A240 / ASME SA240
Dimensions : ASTM, ASME, and API
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Thickness : 4mm-100mm
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Surface Finish : 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| Duplex 2205 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 – 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| 2205 | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
At Russ Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Duplex 2205 Sheets and Plates in Manila, Philippines, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Philippines, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
You’ll find Duplex Steel 2205 Sheet and Plates widely utilized across various industries, including chemical processing, oil and gas, marine, desalination, and power generation. They are particularly well-suited for fabricating tanks, pressure vessels, heat exchangers, and other structural components that face harsh conditions. The blend of strength, corrosion resistance, and durability makes Duplex Steel 2205 Sheet and Plates a top choice for reliable, long-term industrial performance.
