Located in Manila, Philippines, Russ Nickel Alloys has earned a solid reputation as a reliable manufacturer and supplier of top-notch metal products, including Copper Nickel 90/10 Sheets and Plates. Renowned for their precision, strength, and durability, these sheets and plates are crafted to meet international standards for corrosion resistance and mechanical performance. Designed to provide long-lasting reliability in challenging marine, offshore, and industrial settings, Copper Nickel 90/10 Sheets and Plates are perfect for piping systems, heat exchangers, structural components, and condenser applications. With an excellent surface finish, consistent thickness, and outstanding corrosion resistance, they ensure efficiency and safety in every project.
Copper Nickel 90/10 Sheets and Plates are crafted from an alloy that consists of 90% copper and 10% nickel, offering remarkable resistance to seawater corrosion, erosion, and biofouling. They boast high tensile strength, good ductility, and impressive durability even under high pressure and temperature conditions. These sheets and plates maintain their dimensional stability and mechanical integrity throughout fabrication and operation. With excellent thermal conductivity, workability, and corrosion resistance, Copper Nickel 90/10 Sheets and Plates are the go-to choice for marine, offshore, and industrial applications that demand reliable, high-performance materials.
Dimensions : ASTM, ASME and API
Standard :ASTM / ASME SB 171, SB 151
Size : 1 mm to 100 mm
Form : Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc.
Finish : Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Length : Single Random, Double Random & Cut Length
| Grade | Cu | Mn | Pb | Fe | Zn | Ni |
| Cupro Nickel 90/10 | 88.6 min | 1.0 max | .05 max | 1.8 max | 1 max | 9-11 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Cu-Ni 90/10 | 8.1 g/cm3 | 1443 °C (2430 °F) | Psi -80,000, MPa -551 | Psi – 35,000, MPa – 241 | 30 % |
At Russ Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel 90/10 Sheet and Plates in Manila, Philippines, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Philippines, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Copper Nickel 90/10 Sheets and Plates are extensively utilized in situations where strength, corrosion resistance, and durability are crucial. They find common applications in marine and offshore piping systems, heat exchangers, condenser plates, desalination plants, and chemical processing equipment. Additionally, these products are employed in industrial machinery, structural components, and environments exposed to seawater or harsh chemicals. Russ Nickel Alloys’ Copper Nickel 90/10 Sheets and Plates deliver dependable, long-term performance, ensuring safety and efficiency in every application.
