Russ Nickel Alloys, located in Manila, Philippines, is a reputable manufacturer and supplier of high-quality metal products, including Copper Nickel Coils. Renowned for their precision, strength, and durability, these coils are crafted to meet international standards for corrosion resistance and mechanical performance. Designed for longevity in tough industrial, marine, and offshore settings, Copper Nickel Coils are perfect for piping systems, heat exchangers, and condenser applications. They offer consistent thickness, a superb surface finish, and exceptional reliability. Russ Nickel Alloys is committed to ensuring that every product delivers quality, efficiency, and durability for a wide range of engineering projects.
Copper Nickel Coils are crafted from copper-nickel alloys, typically in 70/30 or 90/10 ratios, providing remarkable resistance to seawater corrosion, erosion, and biofouling. They boast high tensile strength, good ductility, and durability even under high pressure and temperature conditions. These coils maintain their shape and mechanical integrity during fabrication while offering excellent thermal conductivity and corrosion resistance. The blend of flexibility, strength, and reliability makes Copper Nickel Coils ideal for marine, offshore, and industrial applications that demand long-lasting performance.
| Grades | Copper Nickel Coils |
| Thickness | 0.1mmThk To 3 mm Thk |
| Width | 3.2mm To 1500mm |
| Length | AS PER CUSTOMER’S REQUIREMENT |
| Type of Material | Cupro Nickel SOFT, DEEP DRAW, EXTRA DEEP DRAW, QUARTER HARD, HALF HARD, FULL HARD. |
| Form | Coil / Strip |
| Test Certificate | Yes. |
| Finish | NO.1, 2B, 2D, 2H, 2R, No.4, HAIRLINE, SCOTCH BRITE, SATIN FINISH, NO.8, BA. |
| Make | BAHRU, POSCO KOREA, POSCO THAINOX, COLUMBUS, ACERINOX, APERAM, TISCO, NISSHIN, NIPPON AND MANY MORE MILLS. |
| Grade | Cu | Pb | Fe | Zn | Mn | Ni+Co |
| C70400 | Balance | ≤ 0.05 | 1.3-1.7 | ≤ 1.0 | 0.3-0.8 | 4.8-6.2 |
| C70600 | Balance | ≤ 0.05 | 1.0-1.8 | ≤ 1.0 | ≤ 1.0 | 9.0-11.0 |
| C71000 | Balance | ≤ 0.05 | 0.5-1.0 | ≤ 1.0 | ≤ 1.0 | 19.0-23.0 |
| C71500 | Balance | ≤ 0.05 | 0.4-1.0 | ≤ 1.0 | ≤ 1.0 | 29.0-33.0 |
| Property | Units | 90-10 | 70-30 |
| Density | kg/dm3 | 8.90 | 8.95 |
| Melting point | °C | 1100-1145 | 1170-1240 |
| Specific heat | J/KGK | 377 | 377 |
| Thermal conductivity | W/mK | 50 | 29 |
| Linear expansion coefficient 10-300°C | 10-6/K | 17 | 16 |
| Electrical resistivity | Micro-ohm/cm | 19 | 34 |
| Modulus of elasticity | GPa | 135 | 152 |
| Modulus of rigidity | GPa | 50 | 56 |
At Russ Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Copper Nickel Coil in Manila, Philippines, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Philippines, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Copper Nickel Coils find extensive use in industries where corrosion resistance, strength, and durability are essential. They’re commonly utilized in marine piping systems, heat exchangers, condenser tubes, desalination plants, and offshore oil and gas equipment. These coils are perfect for being fabricated into sheets, strips, or other components for industrial machinery, pipelines, and structures that face seawater or harsh chemical environments. With Copper Nickel Coils from Russ Nickel Alloys, you can count on secure, long-lasting performance that ensures safety, efficiency, and reliability.
