Russ Nickel Alloys, a premier manufacturer and supplier based in Manila, Philippines, offers high-quality Titanium Grade 2 Tube Fittings designed to meet the demanding needs of various industries. Known for their exceptional corrosion resistance and excellent strength-to-weight ratio, these fittings are ideal for applications in chemical processing, marine environments, and aerospace sectors. Engineered with precision, Russ Nickel Alloys’ Titanium Grade 2 Tube Fittings ensure reliable performance and longevity, making them the preferred choice for critical applications worldwide.
Russ Nickel Alloys is a well-respected manufacturer and supplier located in Manila, Philippines, specializing in high-quality Titanium Grade 2 Tube Fittings that are designed for outstanding performance in critical industrial applications. These fittings are prized for their exceptional corrosion resistance, lightweight design, and impressive formability. Russ Nickel Alloys guarantees that each Titanium Grade 2 Tube Fitting adheres to international quality standards, delivering dependable and durable solutions for sectors like chemical processing, marine, power generation, and aerospace. The company’s dedication to innovation, precision, and customer satisfaction has established it as a reliable source for titanium products.
| Specifications | ASTM B366 / ASME SB366 |
|---|---|
| Size | 1/16 in. to 2 in. & 2mm to 50 mm. |
| Dimensional Range | 1/16 to 2 inches (imperial); 2 to 50 mm (metric) |
| Working Pressures | Upto 2000 to 6000 PSI |
| Thread Type | NPT – ASME B1.20.1, SAE AS71051 | ISO/BSP Parallel – ISO 228 | ISO/BSP Tapered – ISO 7, BS EN 10226-1 | SAE (Unified) – ASME B1.1 |
| End Connections | NPT, ISO/BP, SAE/MS, AN, weld ends, port connectors, sanitary flanges, tube adapters |
| Types | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
| Max Working Pressure | 8MPa | 1200psi Depending on The Tubing Material |
| Working Temperature | -40°C—250°C | -40°F—482°F Depending on The Tubing Material |
| Configurations | Straights, elbows, tees, crosses, caps, plugs, nuts and ferrules Chromatograph and Column End |
| Tube Fitting uses & application |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
Titanium Grade 2 Tube Fittings are primarily made from commercially pure titanium, with small amounts of iron and oxygen that boost strength without sacrificing ductility. They boast excellent mechanical properties, including moderate tensile strength, good weldability, and remarkable corrosion resistance in both oxidizing and mildly reducing environments. These fittings maintain high mechanical integrity at both high and low temperatures, making them perfect for demanding conditions. Their low density and outstanding strength-to-weight ratio ensure durability, longevity, and efficiency across a variety of applications.
Contact us to get a quick quote for your requirement.
You’ll find Titanium Grade 2 Tube Fittings widely used in industries where resistance to corrosion, seawater, and chemical exposure is crucial. They are commonly found in desalination plants, marine and offshore engineering, and chemical processing facilities. In the aerospace sector, they play a role in hydraulic systems and structural assemblies. The medical and pharmaceutical industries also rely on them for their biocompatibility and non-toxic properties. Furthermore, they are utilized in power generation, heat exchangers, and instrumentation systems, ensuring reliable performance and a long service life even in challenging environments.
