Russ Nickel Alloys is a leading manufacturer and supplier of Nickel Alloy 200 forged fittings in Manila, Philippines. Our forged fittings are crafted from high-grade Nickel Alloy 200, known for its exceptional resistance to corrosion, high strength, and reliability under extreme conditions. These fittings are ideal for applications in chemical processing, marine environments, and high-temperature operations. With a commitment to superior quality and precision, we ensure that our products meet rigorous industry standards, providing long-lasting performance. Trust Russ Nickel Alloys for top-notch Nickel Alloy 200 forged fittings that deliver durability and reliability for your most demanding industrial needs.
| Dimension Specification | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
|---|---|
| Thread | NPT, BSPT, BSPP |
| Type | DN15-DN1200 |
| End | Threaded, Welding, JIC |
| Pressure Rating | Threaded end-2000lb/ 3000lb/ 6000lbs Pipe Fittings Socket-weld end-3000/ 6000/ 9000lbs Pipe Fittings |
| Connection | Welding |
| Manufacturing process | Push, Press, Forge, Cast, etc. |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Crosses, Couplings, Reducers, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows – Female-Female, Male-Female, Male-Male, Union, Nipples, Couplings, Plugs Fittings |
| Application |
|
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Nickel | 0.02 max | 0.35 max | 0.35 max | 0.01 max | 0.25 max | 0.40 max | 99.0 min |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 21500 , MPa – 148 | Psi – 67000 , MPa – 462 | 45 % |
Made from commercially pure nickel (at least 99% Ni), Nickel Alloy 200 Forged Fittings boast excellent tensile and yield strength, impressive ductility, and superior corrosion resistance in both reducing and neutral environments. They stand out with their exceptional resistance to alkalis, acids, and chloride stress corrosion cracking, along with good thermal and electrical conductivity. Their strong mechanical properties and resistance to oxidation make them perfect for demanding industrial applications.
Contact us to get a quick quote for your requirement.
These fittings are extensively employed in chemical and petrochemical plants, marine systems, oil refineries, and power generation facilities, connecting pipes, valves, and equipment in high-performance systems. They excel at handling caustic solutions, acids, and corrosive gases in tough industrial environments. With their excellent strength, corrosion resistance, and long-lasting reliability, Nickel Alloy 200 Forged Fittings are the go-to choice for critical, high-performance, and safety-sensitive applications.
