If you’re looking for a top-notch manufacturer and supplier, look no further than this company based in Manila, Philippines, which specializes in high-performance ****. Renowned for its remarkable strength, resistance to corrosion, and ability to handle extreme temperatures, this pipe is designed for tough industrial applications. Russ Nickel Alloys is committed to precision manufacturing and rigorous quality control to ensure they meet international standards. You’ll find Inconel X-750 Pipe widely used in sectors like aerospace, power generation, chemical processing, and marine industries, where it consistently delivers reliable, long-lasting performance even in harsh environments. Its unique blend of durability, high-temperature strength, and oxidation resistance makes it the go-to choice for critical piping systems.
Inconel X-750 Pipe is primarily made up of nickel (around 72%), chromium (14–17%), iron, and trace amounts of titanium, aluminum, and cobalt. This specific composition grants it excellent high-temperature strength, impressive resistance to creep and stress-rupture, as well as superior corrosion and oxidation resistance. On a mechanical level, the pipe boasts high tensile and yield strength, outstanding toughness, and stability in dimensions even at elevated temperatures. Its ability to perform well in both oxidizing and reducing environments makes Inconel X-750 Pipe a reliable option for demanding industrial applications that require long-term dependability.
| Standards : | ASTM B167, B517 / ASME SB167, SB517 |
| Dimensional : | ANSI/ASME B36.19M, ANSI/ASME B36.10M |
| Seamless Pipe Size : | 1 / 2″ NB – 16″ NB |
| Welded Pipe Size : | 1 / 2″ NB – 24″ NB |
| Outside Diameter : | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Tubes available Ex-stock |
| Pipe Type : | Seamless / Welded / ERW / Fabricated / CDW / 100% X Ray Welded |
| Thickness Range : | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Pipes End : | Plain End, Beveled End, Treaded One End, TBE (Treaded Both Ends) |
| Value Added Services : | Cutting, Beveling, Polishing, Threading, Destructive, Non Destructive, Ultrasonic Testing |
| Al | C | Cr | Co | Cu | Fe | Mn | Nb | Ni | Ti | S | Si |
| 0.40-1.0 | .08 max | 14.0-17.0 | 1.00 max | 0.50 max | 5.0-9.0 | 1.00 max | 0.70-1.20 | 70.0 min | 2.25-2.75 | .01 max | .50 max |
| Ultimate Tensile Strength | .2% Yield Strength | Elongation % |
| 1250 MPa, 181000 psi | 850 MPa, 123000 psi | 30 |
| STANDARD | UNS | WNR. |
| Inconel X-750 | N07750 | 2.4669 |
| Density | Melting Range | Curie Temperature,°F | Magnetic Permeability, 70°F, 200H | Linear Contraction during Precipitation Treatment(1300°F/20hr), in/in | ||||
|---|---|---|---|---|---|---|---|---|
| lb/in3 | g/cm3 | °F | °C | As hot-rolled | As Hot-Rolled | Hot-Rolled | 20% Cold-Rolled | Annealed |
| 0.299 | 8.28 | 2540-2600 | 1393-1427 | -225 | 1.0020 | 0.00044 | 0.00052 | 0.00026 |
At Russ Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel X-750 Pipes in Manila, Philippines, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Philippines, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel X-750 Pipe finds extensive use in industries where high strength and corrosion resistance at elevated temperatures are essential. It’s commonly utilized in aerospace components, nuclear power plants, chemical processing, and the petrochemical sector. This pipe is perfect for heat exchangers, boiler tubing, turbine components, and high-pressure piping systems. With its excellent resistance to oxidation, creep, and stress corrosion cracking, it ensures dependable operation under extreme conditions. Inconel X-750 Pipe offers long-lasting durability and requires minimal maintenance, making it a favored choice for critical industrial, marine, and high-temperature applications.
