Russ Nickel Alloys, located in Manila, Philippines, stands out as a top manufacturer and supplier of high-quality nickel-chromium alloy products. Their Inconel 601 Wire is highly regarded for its remarkable resistance to oxidation and impressive mechanical strength, even at elevated temperatures. With a strong commitment to quality and precision, Russ Nickel Alloys ensures that their wire adheres to international standards, serving industries that demand dependable and durable wire solutions for extreme, high-temperature conditions. Their expertise means customers can trust that the Inconel 601 wire they receive is built for long-lasting performance and safety.
The Inconel 601 Wire is primarily crafted from a nickel-chromium alloy, featuring around 58% nickel and 21-25% chromium, along with trace amounts of iron, aluminum, and carbon. This unique blend offers exceptional resistance to oxidation, carburization, and thermal cycling, while also maintaining strength and dimensional stability at temperatures soaring up to 2200°F (1204°C). Additionally, the wire boasts good electrical conductivity and excellent workability.
| Specifications | ASTM B166 ASME SB166, AMS | |
|---|---|---|
| SB 166 UNS N06601 Wires Dimensions | ANSI/AWCI – 01 -1992 and ASTM E 2016-11 and RRW 360 | |
| Alloy 601 Wires Length | 100 mm TO 6000 mm, customizable | |
| ASTM B166 UNS N06601 Wires Diameter | 10 mm To 100 mm or as per client requirement | |
| 2.4851 Alloy 601 Wires Main Types |
|
|
| Alloy 601 UNS N06601 Wires Density | 8.89 g/cm3 | |
|
580-750 | |
|
as standard | |
|
28-30 | |
| Surface | Polished bright, Smooth | |
| Inconel N06601 Wires Technique | Cold Rolled, hot rolled | |
| Din 2.4851 Wires Condition | M, Y, 1/2Hard | |
| Tempers | Tempers range from dead soft annealed to ultra spring temper | |
| Inconel 601 welded wire mesh | Roll Width: 24inch, 36inch, 1Metre, 48inch, 72inch, or 84inch Roll Length: 100feet or 150feet | |
| SB 166 UNS N06601 wire mesh weaving methods | plain weave, twill weave, dutch weave | |
| Offered in a wide range of packages including |
|
|
| Sample | Free sample | |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | ||
| Grade | C | Mn | Si | Cu | S | Cr | Fe | Ni | N |
| Inconel 601 | 0.10 max | 1.00 max | 0.50 max | 1.00 max | 0.015max | 21.00 – 25.00 | bal | 58.0-63.0 | – |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Russ Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 601 Wire in Manila, Philippines, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Philippines, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 601 Wire finds its applications across various sectors, including aerospace, furnace components, heating elements, chemical processing, and power generation. It’s particularly well-suited for creating resistance heating coils, springs, and other high-temperature applications that face corrosive and oxidative environments. Thanks to its durability and corrosion resistance, the wire ensures reliable and safe operation in even the most demanding industrial settings.
