Located in Manila, Philippines, Russ Nickel Alloys has built a solid reputation as a reliable manufacturer and supplier of top-notch alloy products, including Incoloy 825 Pipe Fittings. These fittings are crafted from a specialized nickel-iron-chromium alloy, enriched with molybdenum, copper, and titanium, which grants them remarkable resistance to corrosion, oxidation, and stress-corrosion cracking, even in harsh chemical and high-temperature settings. With a commitment to precision manufacturing and rigorous quality control, Russ Nickel Alloys adheres to international standards, ensuring that their pipe fittings deliver outstanding durability, strength, and consistent performance.
The composition of Incoloy 825 Pipe Fittings features nickel (38–46%), chromium (19.5–23.5%), iron, molybdenum (2.5–3.5%), copper (1.5–3%), and titanium (0.6–1.2%). This thoughtfully balanced mix provides excellent resistance to both reducing and oxidizing acids, as well as pitting, crevice corrosion, and stress-corrosion cracking. These fittings maintain their mechanical integrity, dimensional stability, and high strength at both room and elevated temperatures, ensuring a reliable service life even in demanding conditions.
Specifications : ASTM B366 / ASME SB366
Size : Seamless Inconel / Incoloy Butt Weld Fittings: 1/2″ – 10″
Welded Inconel / Incoloy Butt Weld Fittings: 1/2″ – 48″
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Thickness : SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
Types : Seamless / Welded / Fabricated
Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Inconel Pipe Fittings | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel Pipe Fittings | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
At Russ Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 825 Pipe Fittings in Manila, Philippines, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Philippines, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy 825 Pipe Fittings find extensive use across various industries, including chemical processing, petrochemical, marine, oil and gas, and pollution control. They are particularly well-suited for connecting pipelines in heat exchangers, reactors, pressure vessels, and other equipment that come into contact with corrosive substances and extreme temperatures. Thanks to their exceptional corrosion resistance, mechanical strength, and reliability, Incoloy 825 Pipe Fittings are the go-to choice for critical industrial applications that demand safety, durability, and long-lasting performance.
