Home > Haynes 230 Sheets and plates
Russ Nickel Alloys, a leading manufacturer and supplier based in Manila, Philippines, specializes in providing premium-quality Haynes 230 sheets and plates. Renowned for their exceptional heat and oxidation resistance, these sheets and plates are widely used in high-temperature applications across industries like aerospace, power generation, and chemical processing. With a commitment to quality, precision, and reliability, Russ Nickel Alloys ensures products meet international standards, catering to diverse client requirements with unmatched expertise and customer service.
| Specification : | AMS 5878 |
| Standard : | AMS, AMS, API |
| Specialize sheets : | Shim, Perforated Sheet, B. Q. Profile. |
| Size : | 0.5 MM TO 200 MM THICK IN 1000 MM TO 2500 MM WIDTH & 2500 MM TO 12500 MM LENGTH |
| Finish : | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness : | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade : | Haynes 230 (UNS N06230) |
| Weight% | C | Mn | Si | P | S | Cr | Co | Fe | Al | Ti | B | Cu | La | W | Mo | Ni |
| Haynes 230 | 0.05-0.15 | 0.30-1.0 | 0.25-0.75 | 0.03 | 0.015 | 20.0-24.0 | 5.0 | 3.0 | 0.20-0.50 | 0.10 | 0.015 | 0.50 | 0.005-0.05 | 13.0-15.0 | 1.0-3.0 | Rem |
| Material | Test Temp °F | Ultimate Tensile Strength | 0.2 % Yield Strength | Elongation in % | Hardness HB |
| Haynes Alloy 230 Extruded Bar Solution Treated (AMS 5891) | RT | 758 Mpa 110 ksi | 310 Mpa 45 ksi | 35 | 241 max |
The Haynes 230 sheets and plates from Russ Nickel Alloys are primarily made of nickel, chromium, tungsten, and molybdenum, engineered to endure extended exposure to high temperatures. This alloy boasts exceptional oxidation resistance up to 1149°C (2100°F), along with impressive strength and structural integrity. Its mechanical properties feature a tensile strength of about 760 MPa, high creep resistance, and good formability. Russ Nickel Alloys upholds strict quality control measures to guarantee that each sheet and plate meets precise specifications, making them perfect for critical applications where mechanical strength and corrosion resistance are paramount.
Contact us to get a quick quote for your requirement.
The Haynes 230 sheets and plates provided by Russ Nickel Alloys find their place in demanding settings, such as gas turbines, combustion liners, industrial furnaces, and heat treating equipment. Their remarkable high-temperature capabilities also render them suitable for nuclear power systems and aerospace engine components. These sheets and plates are designed to perform reliably under thermal cycling and mechanical stress, ensuring long-lasting durability.
