Russ Nickel Alloys, located in Manila, Philippines, has built a solid reputation as a reliable manufacturer and supplier of top-notch nickel-iron alloy products. Their Incoloy 800/800H/800HT Stud Bolts are particularly well-regarded for their outstanding resistance to corrosion and impressive mechanical strength, even at high temperatures. With a strong commitment to quality and precision, Russ Nickel Alloys ensures that their stud bolts adhere to international standards, making them perfect for industries that need dependable and durable fastening solutions in tough environments. Their expertise means customers can trust that they’re getting stud bolts designed for long-lasting performance and safety.
These stud bolts are crafted from a nickel-iron-chromium alloy, which typically contains around 30-35% nickel and 19-23% chromium, along with some iron, copper, and aluminum. The 800H and 800HT grades undergo heat treatment to enhance their strength at high temperatures and improve their resistance to creep. Thanks to their excellent resistance to oxidation, carburization, and stress corrosion cracking, these stud bolts maintain their mechanical integrity and dimensional stability, even in the most challenging thermal and corrosive conditions.
| Stud Bolt size | M02 to M33, Custom Sizes |
|---|---|
| Stud Bolts Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard of Stud Bolts | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form of Stud Bolts | Hex, Threading, Square, Round as per Gauge Etc. |
| Raw materials Source | JSPL, Mukund Steel, Tata Steel, Dhamm Steel, Usha Martin, etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Popular Types of Stud Bolt | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate of Stud Bolts | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Stud Bolts Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Stud Bolts finishing | Coatings & Finishes : Self-Colour, Passivated, Bright Zinc Plated (BZP), Hot Dip Galvanised (HDG), Sherardized, some special one like DACROMET Geometry and Mechanically Applied coating ,Dacroment, nickel plated, anodizing, plated zinc-nickel Zinc (blue, black, yellow, white), black oxide, |
| Grade | C | Mn | Si | S | Cr | Fe | Ni |
| Incoloy 800 | 0.1 max | 1.5 max | 1.0 max | 0.015max | 19.0 – 23.0 | 39.5 min | 30.0 – 35.0 |
| Incoloy 800H | 0.05 – 0.1 | 1.5 max | 1.0 max | 0.015 max | 19.0 – 23.0 | 39.5 min | 30.0 – 35.0 |
| Incoloy 800HT | 0.06 – 0.1 | 1.5 max | 1.0 max | 0.015 max | 19.0 – 23.0 | 39.5 min | 30.0 – 35.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 800 / 800H / 800HT | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
At Russ Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy 800/800H/800HT Stud Bolts in Manila, Philippines, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Philippines, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy 800/800H/800HT Stud Bolts find their place in various industries, including chemical processing, power generation, petrochemical, and aerospace. They’re particularly suited for securing flanges, valves, and equipment that face high temperatures and corrosive environments, like reactors and heat exchangers. The remarkable durability and corrosion resistance of these stud bolts ensure safety and reliability in critical industrial applications.
